Portable Blackbody Calibration Verification Unit For Human Skin Temperature

picto fleche
  • Portable Blackbody Calibration Verification Unit For Human Skin Temperature - HSB50 1 - AOIP

. Designed specifically as a benchmark for measuring human skin temperature

. Accuracy of + 0.5 ° C @ 37.0 ° C (98.6 ° F)

. Includes NIST certificate of compliance at 37 ° C (98.6 ° F) with virtually no errors or lag

. Emissivity of 0.98 for calibrating instruments used for measuring human skin temperature Unique design with extremely high emissivity, precision, stability and uniformity

. Large emission area: 2.83 x 2.83 in (72×72 mm)

. Integrated handle for easy transport

. Tripod Seat for temporary or permanent installation on site

. 85 to 250VAC can be used anywhere in the world

. Includes 6ft power cord with proper power connection

Poser une question
Etre rappelé par un conseiller

Aperçu

As a high precision reference device to check the reading of your portable infrared thermometers and thermal cameras.
As a reference to provide higher precision measurements for thermal imaging temperature scanning systems.
The integrated handle makes this lightweight unit easy to transport and install on any horizontal surface. It is equipped with a 1/4 "x 20 UNC thread tripod for standard camera at the bottom of the unit, which allows it to be attached to a tripod for on-site temperature monitoring with infrared and Portable or fixed / mounted thermal imagers The HSB50 can be used anywhere in the world with 85 to 250VAC.

Model HSB50 SPECIFICATIONS

Temperature Range :

Ambient + 5°C (122°F)

Controller:

User Adjustable

Display Resolution:

0.1°F or 0.1°C

Aperture (Target Size):

2.83 x 2.83 in (72 x 72 mm) Square Plate

Emissivity

0.98 + 0.002 - emissivity of human skin

Spectrum :

8 to 14 microns

Calibration Method :

Pyrometric Calibration - with a highly accurate non-contact transfer-standart during production

Accuracy:

+0.05°C @ 37.0°C (98.6°F)

Uniformity:

+ 0.15°C , within a central area diameter of 51 mm(2")

Stability :

+0.1°C

Warm-up Time @23°C :

10 minutes (after stabillizing at ambient before start-up)

Power :

30 Watts

Power connector:

IEC320 with appropriate power connector for country

Voltage:

85 to 250VAC

Dimensions H x W x D:

5x5x7 in (127 x 127 x 177.8 mm)

Weight :

9.25 lbs. (4.2kg)

Portability :

Built-in Handle, lightweight and easy to carry

Mouting:

Bench top or Tripod Mount (1/4"x20UNC Thread)

Optical PC Interface:

RS485

Optional Accessories :

Tripod

Included :

NIST Certificate of Conformance at three points : 96.8°F (36.0°C), 98.6°F ( 37.0°C) and 100.4°F (38.0°C) 12453-03 All Purpose Microfiber Cleaning Cloth in zip-close pouch, 8"x8"



HSB50- BLACKBODY CALIBRATION VERIFICATION UNIT FOR HUMAN SKIN TEMPERATURE

step 1-select: model

Code

description

HSB50

Blackbody calibration verification unit, aperture: 2.83 x 2.83 in (72x72mm), includes NIST Certificate of conformance

Step 2 - Select : Temperature Scale

Code

temperature scale

C

Ambient +5° to 50°C

F

Ambient + 5 to 122°F



Step 3 - Select: power connector ( incluse dash)

Code

Power Connector

-US

North American Power cord, IEC320 to NEMA 5-15P, 6 ft

-BR

Brazil Power Cord, IEC320 to 3P, 6 ft

-CN

China, AU & NZ Power Cord, IEC320 to AS3112, 6 ft

-EU

EU Power Cord , IEC320 to BS1363, 6 ft

-UK

UK Power Cord, IEC320 to BS1363, 6ft

-XX

Other,Specify with Country Code and Connection Description



Step 4 - Select: Option

Code

Option

P

RS485 PC Interface

X

Other

Series

Temperature Scale



Power Connector



Options

HSB50







Insert Codes in boxes above to build par number
